LANKELEISI KETT-8 Urban Electric Bike

Name: LANKELEISI KETT-8 Urban Electric Bike
Brand: lankeleisi.eu
SKU: KETT-8-Orange
Price: 2199.0 EUR
Availability: InStock

Your cart is empty

Continue shopping

250W

Motor

48V 20Ah

Samsung Battery

25KMH

Max speed tested

150 KM

Per Charge

180KG

Payload Capacity

160-190CM

Applicable height

Essai du KETT-8

Lankeleisi KETT8 - Ils l'ont fait ! le voila le vélo parfait ! (adieu mon mg600)

MobiliTest

BRUSHLESS DRIVE MOTOR

With a 250 W rated output and peak power up to 1130 W, the motor provides responsive assistance when needed while remaining energy efficient.Refined internal optimisation reduces mechanical loss and noise, supporting stable performance and extended riding range.

85NM

Max Torque

35°

Climbing Angle

48V 20Ah SAMSUNG Li-ion Battery

The bike is driven by a 48V 20Ah Samsung 21700 lithium battery, neatly concealed within the frame for a sleek look. Advanced battery management and protection systems provide steady energy output, ensuring reliable performance whether on daily commutes or long-distance adventures.

55~150 KM

Per Charge

960Wh

Total Battery Capacity

48V 3A

Charger

6-7 hours

Fully Charged

SUSPENSION FRONT FORK

The front suspension fork features 120 mm of travel, helping absorb impacts and improve control on uneven surfaces.Combined with 26 x 3.0" wide tires, it delivers added comfort, stability, and confidence on urban roads and light off-road terrain.

120mm

Suspension travel

26X3.0"

Tire size

LCD Color Display

Colour Backlight Display to keep track of speed, mileage, power and more.

Battery Capacity

Battery level display

Odometer

Total Ride Mileage

Pedal-Assist Level

Pedal assistance power

Speedometer

Display current speed, maximum speed and average speed

Waterproof Level

IP64

Front and rear drive switching

Switch motor power output, single or dual motor

Other Highlights

SHIMANO 8-SPEED DRIVETRAINS

A reliable 8-speed system with a 48T aluminum chainring and Shimano SIS indexing, delivering smooth, consistent shifting for everyday riding.

ZOOM HYDRAULIC DISC BRAKES

ZOOM four-piston hydraulic disc brakes with motor cut-offf unction deliver strong, precise braking and consistent control for urban and light off-road riding.

THUMB THROTTLE

This electric bicycle is equipped with a practical thumb throttle, allowing smooth acceleration and precise control with just one thumb. Its simple design supports easy removal, making use and maintenance more convenient.

SOFT-TAIL FRAME

Optional DNM air shock with air pressure,rebound, and compression adjustment,plus lockout function.Delivers 105 mm rear suspension travel and supports up to 200 kg total load.

Cadence & Torque Sensing Assist

The system combines cadence sensing and torque sensingto deliver assistance that responds naturally to rider input. By accurately matching pedaling force and cadence,it provides smooth,intuitive support while improving efficiency and helping extend riding range.

NIGHT LIGHTING SYSTEM

High-brightness LED headlight taillight improvevisibility in low-light conditions.Integrated turn signals and brake light enhance awarenessand safety when riding at night.

26*3.0 FAT TIRES

Combined with 26 x 3.0" wide tires, it delivers addedcomfort, stability, and confidence on urban roads and lightoff-road terrain.

ERGONOMIC COMFORT & UTILITY

An ergonomic saddle provides balanced support for sporty yet comfortable riding.The aluminum rear rack adds everyday carrying capability,while aluminum fenders help keep rides clean and controlled in all conditions.

48V Luminous Taillight

Enhances rider visibility at night and in low visibility conditions, warns other road users and directs the movement of riders to ensure safe riding at night.

ALUMINUM ALLOY FRAME

Built from 6061-T6 aluminum alloy, the frame is engineered for strength, durability, and corrosion resistance.Precision heat treatment ensures reliable structural integrity and consistent support, delivering a stable and confident ride across urban streets and light off-road terrain.

About KETT-8

Specifications

FRAMESET
Frame	6061 aluminum soft-tail frame
Fork	Lockable suspension fork, 120 mm travel
Rear Suspension	Soft-tail rear suspension, 105 mm travel, Air shock compatible with rebound and compression adjustment
Handelbar Sets	Aluminum alloy handlebar with adjustable aluminum stem
Cranksets	48T Aluminium Alloy Crankset
Rim	26" aluminum alloy rims
Brake	ZOOM four-piston hydraulic disc brakes with motor cut-off
Tire	KENDA 26*3.0 size Tires
ELECTRONICS
Motor	48V rear hub motor (rated 250W/ peak 1130W, maximum 85Nm)
Battery	960 Wh (48V, 20Ah) Samsung 21700 lithium-ion battery
controller	48v 23a Vector SineWave Controller
LCD Display	4" color smart LCD display
Front light	Integrated LED headlight and rear taillight with turn signal function
Charger	48V 3A charger
Throttle	Half Twist
Power assist Sensor	Integrated torque sensor
Waterproof Grade	IP64 (waterproof for daily use, suitable for use in rain)
SPEED & RANGE	Riding conditions tested: After being fully charged, the load is 60kg, the temperature is 25 ℃, and the test is conducted at 20km/h. The actual measurement is the average speed on a flat road surface
Top speed	25 km/h (motor assistance limit) - Motor assistance complies with local regulations. Higher speeds may be enabled for private property use.
Range	Up to 150km* - Actual range varies with terrain, rider weight, temperature, and riding mode.
Climbing Capability	Up to 35% - Performance may vary depending on rider input and surface conditions.
Gear Systems
Variable speed	SHIMANO 8-speed drivetrain
Shifting Lever	Shimano M315-7 finger dial (Note: This appears to be 7-speed; new drivetrain is 8-speed, but no new lever specified. Retained from original unless a new 8-speed lever is intended.)
Rear Derailleur	Shimano M310 (Note: This is a 7-speed derailleur; new drivetrain is 8-speed. Retained from original unless a new 8-speed derailleur is intended.)
Chain	KMC 7s (Note: This is a 7-speed chain; new drivetrain is 8-speed. Retained from original unless an 8-speed chain is intended.)
WEIGHT & LOAD
Bike Weight	Net: 35.4 kg (Weight may vary 3-5%. Net weight includes battery, excludes accessories.)
Max Bike Load	180 kg
Rear rack Load Capacity	25 kg

Geometry
